• New 4.0 user interface
• 16-channel decoding @1080p (30 fps); self-adaptive decoding capability
• Access, storage or forwarding at 384 Mbps
• Simultaneous video output for VGA and HDMI1; 4K heterogeneous output for the 2 HDMI ports
• Multiple data mode such as Raid0, Raid1, Raid5, Raid6, and Raid10
• Remote configuration and management of IPCs, such as setting pa rameters, acquiring information and upgrading IPCs of the same model in batches
• AI-by-camera functions such as perimeter protection, face detection and recognition, SMD Plus, video metadata, ANPR and 3D behavior analysis
• N+M cluster. When the host fails, the standbydevice will continue to record; once the host recovers,video recorded on the standby device will be transmitted back
| Dosyalar |
| NVR616-64-4KS2-DataSheet |
Download |
| System |
| Main Processor |
Intel Quad Core Processor |
| Operating System |
LINUX |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Ringer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22×18), Video Loss and Tampering |
| Alarm input |
16 Channels, Low Level Effect, Green Terminal Interface |
| Playback and Backup |
| Playback |
128 Mbps in Raid 5 Mode;
64 Mbps in Single HDD Mode |
| Search Mode |
Time/Date, Alarm, MD and Exact Search (accurate to seconds) |
| Audio and Video |
| IP Camera Input |
64ch |
| Multi-screen Display |
1. Display: 1/4/8/9/16/25/36
2. Display: 1/4/8/9/16 |
| Third-party Support |
| Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek ve daha fazlası |
| Video |
| Compression |
H.265/H.264/MJPEG |
| Interface |
4 RJ-45 Bağlantı Noktası (10/100/1000Mbps) |
| Resolution |
12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P vb. |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Bit Rate |
16Kbps ~ 20Mbps |
| Record Interval |
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Network |
| Network Protocol |
HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filtresi, PPPoE,DDNS, FTP, Alarm Sunucusu, IP Arama (Destek Dahua IP kamera, DVR, NVS, vesaire.) |
| Interoperability |
ONVIF 2.4, CGI Uyumlu |
| Max. User Access |
128 |
| Smart Phone |
iPhone, iPad, Android |
| Ethernet Port |
4 Ethernet Ports Collaborative or 4 Independent 1000Mbps Ethernet Ports |
| Optical Fiber Interface |
2 Giga Fiber Optic Interface |
| Port |
| HDD Interface |
16 SATA III Ports, up to 8TB capacity for each HDD |
| Two-way Audio |
1 Channel In, 1 Channel Out, RCA |
| USB |
4 USB Ports (2 USB 2.0, 2 USB 3.0) |
| SAS |
1 Mini SAS Port for Storage Expansion |
| RS-232 |
1 Port for PC Communication and Keyboard |
| eSATA |
1 eSATA Port (Please contact technical engineer to confirm compatible device) |
| Certifications |
| Certifications |
CE : EN55022, EN55024, EN50130-4, EN60950-1
FCC : Part 15 Subpart B, ANSI C63.4-2014
UL : UL 60950-1 and CAN/CSA C22.2 No.60950-1 |
| General |
| Operating Temperature |
10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Installation |
Rack Mounted |
| Recording Playback |
| Record Mode |
Manual, Schedule (Normal, MD (Motion Detection), Alarm, IVS), Holiday, Stop |
| Backup Method |
USB Device/Network/eSATA Device |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Electrical |
| Power Supply |
AC100V ~ 240V, 50 ~ 60 Hz |
| Power Consumption |
<51W (without HDD) |
| Interface |
| Relay Output |
8 Channels, NO/NC Programmable, Green Terminal Interface |
| RS485 |
1 Port for PTZ Control |
| Packaging |
| Gross Weight |
27 kg (59,5 lb) |
| Environmental |
| Strorage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
| Construction |
| Dimensions |
3U, 485 mm x 512,9 mm x 133,2 mm (19,1" x 20,2" x 5,2") |
| Net Weight |
17.6 kg (38.8 lb) (without HDD) |
