• 16-channel IP video access
• Smart H.265+/Smart H.264+/H.265/H.264/MJPEG; H.265 auto switch
• Max 320 Mbps incoming bandwidth
• Up to 24MP resolution for live view and playback
• 1-channel fisheye dewarping (AI by NVR)
• AI by Camera: Perimeter protection; face detection and recognition; SMD Plus; video metadata; ANPR; people counting; stereo analysis; crowd distribution; heat map
• Support IPC UPnP, 16 PoE ports
| Dosyalar |
| NVR5216-16P-4KS2E -DataSheet |
Download |
| System |
| Main Processor |
Industrial-grade embedded processor |
| Operating System |
Linux |
| Operating Interface |
Web; Local GUI |
| Perimeter Protection by Camera |
| Performance |
16ch |
| AI Search |
Search images by channel, time and event type |
| Face Detection by Camera |
| Performance |
14ch |
| Face Attributes |
6 features: Gender, age, glasses, expression, mouth mask and beard |
| AI Search |
Search images by channel, time and event type |
| SMD Plus by Camera |
| Performance |
16ch |
| AI Search |
Search by target classification (person, vehicle) |
| Audio and Video |
| Access Channel |
16 |
| Network Bandwidth |
320 Mbps, depolama için 320 Mbps ve yönlendirme için 320 Mbps |
| Resolution |
12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1,3MP, 720p, D1 |
| Decoding Capability |
16 kanal@1080P (30 fps) |
| Video Output |
HDMI1: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720
VGA1: 1920 × 1080; 1280 × 1024; 1280 × 720 |
| Multi-screen Display |
1, 4, 8, 9, 16 views |
| Third-party Camera Access |
Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon |
| Compression Standard |
| Video Compression |
Smart H.265+; SmartH.264+; H.265; H.264; MJPEG |
| Audio Compression |
PCM; G.711A; G.711U; G.726 |
| Network |
| Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS'ler; IP Filtresi; PPPoE; DDNS; FTP; Alarm Sunucusu; IP Arama (Dahua IP kamera, DVR, NVS ve daha fazlasını destekler.) ; P2P |
| Mobile Phone Access |
Android; iOS |
| PoE |
16 |
| Interoperability |
ONVIF (profil T/S/G); CGI; SDK |
| Browser |
Chrome; IE9 or later; firefox |
| Port |
| Audio Input |
1 |
| Audio Output |
1 |
| HDD Interface |
2 SATA III ports for a single HDD up to 10TB. Maximum HDD capacity varies depending on ambient temperature. |
| USB |
2 (1 × front USB2.0; 1 × rear USB2.0) |
| HDMI |
1 |
| VGA |
1 |
| Network Port |
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port |
| General |
| Dimension |
375,0 mm × 327,4 mm × 53,0 mm (14,8" × 12,9" × 2,1") |
| Operating Temperature |
-10°C ila +55°C (+14°F ila +131°F) |
| Certifications |
CE: EN55032; EN55024; EN50130-4; EN60950-1
FCC: Bölüm 15 Alt Bölüm B; ANSI C63.4-2014
UL: UL 60950-1 |
| Recording Playback |
| Multi-channel Playback |
1/4/9/16 |
| Record Mode |
Manual; program (general;MD;alarm;MD&alarm;smart;POS) |
| Storage Method |
Local HDD and network |
| Backup Method |
USB |
| Playback Function |
1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (video clip/file); partially zom in; audio on/off |
| Alarm |
| General Alarm |
Motion detection, privacy masking, video loss, scene switching, PIR alarm, IPC external alarm |
| Anomaly Alarm |
Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception |
| Intelligent Alarm |
Face detection, perimeter protection (intrusion and trigger wire), IVS, people counting, heat map and SMD alarms |
| Alarm Linkage |
Recording, snapshot, audio, ring, log, preset and email |
| Electrical |
| Power Supply |
100V–240V AC, 50 Hz–60 Hz |
| Power Consumption |
NVR: < 15.2W (without HDD)
PoE: Maximum 25.5W for single port
130W total rated power, 80% control for protection |
| Interface |
| Alarm I/O |
4/2 |
| Environmental |
| Operating Humidity |
10%–93% (RH) |
| Construction |
| Net Weight |
2,7 kg (6,0 lb) |
| Gross Weight |
4 kg (8,8 lb) |
