• 5MP, 1/2.7” CMOS image sensor,low illuminance, high image definition
• Outputs max. 5MP (2592 × 1944) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps
• H.265 codec, high compression rate, ultra-low bit rate
• Built-in IR LED, max IR distance: 40 m
• ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
• Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
• Intelligent detection: Intrusion, tripwire
• Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection
• Supports max. 256 GB Micro SD card
• 12V DC/PoE power supply
• IP67 protection
| Dosyalar |
| IPC-HDW2531T-AS-0280B-S2-DataSheet |
Download |
| Camera |
| Image Sensor |
1/2.7” 5Megapixel progressive CMOS |
| Effective Pixels |
2592 (H) × 1944 (V) |
| RAM/ROM |
256MB/128MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
| Minimum Illumination |
0.008 Lux @ F1.6 |
| S/N Ratio |
56dB |
| IR Distance |
30m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
2 |
| Lens |
| Lens Type |
Fixed |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.6 |
| Angle of View |
2.8 mm:
Horizontal 103.0° × Vertical 71.0° × Diagonal 132.0°
3.6 mm:
Horizontal 84.0° × Vertical 58.0° × Diagonal 110.0° |
| Close Focus Distance |
2.8 mm: 0.9 m (2.95 ft)
3.6 mm: 1.6 m (3.61 ft) |
| PTZ |
| Pan/Tilt Range |
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360° |
| Video |
| Compression |
H.265; H.264; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+/ Smart H.264+ |
| Streaming Capability |
2 Streams |
| Frame Rate |
Main stream:
2592 × 1944 (1 fps-20 fps)
2688 × 1520 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps) |
| Resolution |
2592×1944(2592×1944); 2688×1520(2688×1520); 3M(2048×1536); 2304×1296(2304×1296); 1080p(1920×1080); 1.3M (1280 × 960); 720p(1280×720); D1(704× 576/704×480); VGA(640×480); CIF(352×288/352×240) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 32 Kbps–8192 Kbps
H.265: 12 Kbps–8192 Kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC Mode |
Yes |
| HLC |
Yes |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| WDR |
120dB |
| Noise Reduction |
3D DNR |
| Region of Interest |
Off / On (4 Zone) |
| Motion Detection |
Off / On (4 Zone, Rectangle) |
| Smart IR |
Yes |
| Image Rotation |
0°/90°/180°/270° (Supports 90°/270° with 2592 × 1944 resolution and lower.) |
| Mirror |
Off / On |
| Privacy Masking |
4 areas |
| Audio |
| Compression |
G.711A; G.711Mu; G.726 |
| Built-in MIC |
Yes |
| Network |
| Ethernet |
RJ-45 (10/100 Base-T) |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
| Max. User Access |
20 |
| Edge Storage |
FTP; Micro SD card (support max. 256 G); NAS; SFTP |
| Web Viewer |
IE
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Smart Phone |
IOS, Android |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Certifications |
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Electrical |
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
< 7.2W |
| Environmental |
| Operating Conditions |
-40°C to +60°C (-40°F to +140°F)/less than ≤ 95% |
| Strorage Conditions |
-40°C to +60°C (-40°F to +140°F) |
| Ingress Protection |
IP67 |
| Construction |
| Casing |
Metal + Plastic |
| Dimensions |
100.9 mm × Φ109.9 mm (3.97" × Φ4.33") |
| Net Weight |
0.39 kg (0.9 lb) |
| Gross Weight |
0.56 kg (1.2 lb) |
