• Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
• Max. decoding capability: 32 × 1080p@30 fps.
• Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth.
• Supports AcuPick with up to 64 channels.
• AI by Recorder supports 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus.
• AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
• Supports N+M cluster, Raid 0/1/5/6/10, ISCSI, Drawer-like chassis design allows for HDD hot swapping.
• Supports EPTZ, One-click Arming & Disarming.
• Security baseline 2.3.
| Dosyalar |
| NVR608H-128-XI -DataSheet |
Download |
| System |
| Main Processor |
Industrial-grade embedded processor |
| Operating System |
Linux |
| Operating Interface |
Web; Local GUI |
| AI |
| AI by Camera |
Face recognition; face recognition; video metadata (human, motor vehicles and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; counting people; ANPR; vehicle density; object tracking |
| AI by Recorder |
Face recognition; face recognition; video metadata (human, motor vehicles and non-motor vehicles); SMD Plus |
| AcuPick AI by Camera + Recorder |
Max. 64 channels, 1 composite event per channel/sec |
| Face Detection by Camera |
| Face Attributes |
Top color, top type, hat, bag, age, gender and umbrella |
| Smart Event |
| SMD PLUS |
32 channels: Secondary filtering for people and motor vehicles, reducing false alarms caused by leaves, rain and changing lighting conditions |
| Audio and Video |
| Access Channel |
128 |
| Network Bandwidth |
AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing |
| Resolution |
32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1 |
| Decoding Capability |
AI disabled: 2ch 32MP@30fps; 2ch 24MP@30fps; 4ch 16MP@30fps; 5ch 12MP@30fps; 8ch 8MP@30fps; 12ch 5MP@30fps; 16ch 4MP@30fps; 32ch 1080p@30fps; 64ch D1@30fps AI enabled: 1ch 32MP@30fps; 1ch 24MP@30fps; 2ch 16MP@30fps; 2ch 12MP@30fps; 4ch 8MP@30fps; 6ch 5MP@30fps; 8ch 4MP@30fps; 16ch 1080p@30fps; 64ch D1@30fps |
| Video Output |
2 VGA, 4 HDMI; VGA: 1920×1080, 1280×1024, 1280×720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680×4320, 3840×2160, 1920×1080, 1280×1024, 1280×720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode: max. The resolution of VGA1 and VGA2 is 1080p; max. The resolution of HDMI1 and HDMI2 is 4K; max. The resolution of HDMI3 is 8K; max. HDMI4 resolution is 1080p Heterogeneous mode: Simultaneous video source output for VGA1 and HDMI1, simultaneous video source output for VGA2 and HDMI2. Max. The resolution of VGA1 and VGA2 is 1080p; max. The resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. The resolution of HDMI4 is 1080p |
| Multi-screen Display |
Main screen: 1/4/8/9/16/25/36/64
Sub screen: 1/4/8/9/16 |
| Third-party Camera Access |
ONVIF; Panasonic; sony; Eksen; Arecont; Pelco; Kanon; SAMSUNG |
| Compression Standard |
| Video Compression |
Smart H.265+; SmartH.264+; H.265; H.264; MJPEG |
| Audio Compression |
G.711a; G.711u; PCM; G726 |
| SMD Plus |
| SMD Plus by Camera |
64 ch |
| Network |
| Network Protocol |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), P2P, iSCSI |
| Mobile Phone Access |
Android; iOS |
| Interoperability |
ONVIF 22.12 (Profil T; Profil S; Profil G); CGI; SDK |
| Browser |
Chrome;IE;Safari;Edge;Firefox |
| Port |
| Audio Input |
1 |
| Audio Output |
2 |
| HDD Interface |
8 SATA ports, up to 16TB. Maximum HDD capacity varies depending on ambient temperature. |
| USB |
4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports) |
| Network Port |
2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports |
| RS-232 |
1 |
| Video Metadata |
| Human Attributes |
top, top color, bottom, bottom color, hat, bag, gender, age, umbrella |
| Non-motor Vehicle Attributes |
Vehicle model, vehicle color, number of people, helmets. |
| General |
| Dimension |
444,0 mm × 456,6 mm x 95,0 mm (17,48" × 17,98" × 3,74") (G × D × Y) |
| Operating Temperature |
–10 °C ila +55 °C (14 °F ila +131 °F) |
| Certifications |
FCC: 47 CFR FCC Bölüm 15, Alt BölümB, Sınıf A CE-EMC: EN 55032:2020, Sınıf A; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014+A11:2017 |
| Recording Playback |
| Multi-channel Playback |
up to 16 channels |
| Record Mode |
Manual; alarm; Motion detection; planned |
| Storage Method |
Yes |
| Playback Function |
1. Play, pause, stop, fast forward, fast rewind, rewind, play by frame
2. Full screen, backup (cut/file), partially enlarge, volume up/down |
| Vehicle License Plate Comparison |
| ANPR by Camera (Number of Channels) |
64 |
| Alarm |
| General Alarm |
Motion detection; privacy masking; video loss; local alarm; PIR alarm; IPC alarm |
| Anomaly Alarm |
Camera is offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly |
| Intelligent Alarm |
Face recognition; environmental protection; face recognition; video metadata (human, motor vehicles and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; counting people; ANPR; vehicle density; temperature map |
| Alarm Linkage |
Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; sound; buzzer; daily, preset; email |
| Electrical |
| Power Supply |
100–240 VAC, 50/60Hz |
| Power Consumption |
<18 W (without HDD) |
| Interface |
| RS485 |
1 |
| Alarm I/O |
16/8 |
| Environmental |
| Perimeter Performance of AI by Camera (Number of Channels) |
64ch |
| Operating Humidity |
%10–%93 |
| Construction |
| Net Weight |
6.40 kg (14.11 lb) (without HDD) |
| Gross Weight |
10.35 kg (22.82 lb) (without HDD) |
