• 12 MP 1/1.7" CMOS image sensor, low luminance, and high definition image.
• Outputs max. 12M (4000 × 3000)@25 fps; supports 8M (3280 × 2480)@25/30 fps.
• Built-in IR LED, and the max. illumination distance is 10 m.
• Intelligent monitoring: Intrusion, tripwire, heat map, and people counting.
• SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
• Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual-array Mic and speaker.
• 12 VDC/PoE power supply.
• IP67 and IK10 protection.
| Dosyalar |
| IPC-EBW81242-AS-S2-DataSheet |
Download |
| Camera |
| Image Sensor |
1/1,7" CMOS |
| Effective Pixels |
4000 (Y) × 3000 (D) |
| RAM/ROM |
4GB/2GB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3(4)~1/100000s |
| Minimum Illumination |
0,01 Lüks@F2,0 (Renkli, 30 IRE)
0,001 Lux@F2,0 (S/B, 30 IRE)
0 Lux (Aydınlatıcı açık) |
| S/N Ratio |
>56dB |
| IR Distance |
10m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
3 |
| Lens |
| Lens Type |
Fixed Focus |
| Mount Type |
M12 |
| Focal Length |
1,85 mm |
| Max. Aperture |
F2.0 |
| Angle of View |
Y: 185°; D: 180° |
| Close Focus Distance |
0,4 m (1,31 ft) |
| Video |
| Compression |
H.265; H.264; H.264H; MJPEG |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| Streaming Capability |
3 Streams |
| Frame Rate |
Main stream: 4000 × 3000@(1–25/25 fps)
substream: 704 × 576@(1–25/30 fps)
third stream: 1280 × 960@(1–17/17 fps)
Fisheye mode:
1O (4000×3000)
1P (4096×1024)
2P (2432×2432)
1R (1216×1216)
2R (2432x2432)
4R (2432×2432)
1O+3R (2432x2432)
*The values above are maximum values. frame rates of each stream; Values for multiple streams will be subject to total coding capacity. |
| Resolution |
4000x3000; 3280x2480; 2880x2160; (3M) 2048x1536; 1,3M (1280x960); D1 (704x576/704x480); CIF (352x288/352x240) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H264: 8 kbps–16384 kbps
H265: 3 kbps–16384 kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC Mode |
Yes |
| HLC |
Yes |
| White Balance |
Auto; natural; Street lamp; outdoor; Manual; regional tradition |
| Gain Control |
Auto/Manual |
| WDR |
DWDR |
| Noise Reduction |
3D DNR |
| Region of Interest |
Off / On (4 Zone) |
| Motion Detection |
Off / On (4 Zone, Rectangle) |
| Mirror |
Off/On |
| Privacy Masking |
Closed / Open (4 Fields, Rectangular) |
| Audio |
| Compression |
PCM; G.711A; G.711Mu; G.726; G.723 |
| Built-in MIC |
Yes, built-in dual Microphone |
| Network |
| Ethernet |
RJ-45 (100/1000Base-T) |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS'ler; DDNS; QoS; UPnP; NTP; Çok noktaya yayın; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability |
ONVIF (Profil S/Profil G/Profil T); CGI; Dönüm noktası; Genetec; P2P (Yalnızca genel sürüm tarafından desteklenir) |
| Max. User Access |
20 |
| Edge Storage |
FTP; SFTP; Micro SD card (support max. 256G); of NAS |
| Web Viewer |
IE: IE11, IE10
Chrome: 48.0.2564.116
Firefox: 48.0.2
Edge: 42.17134.1.0 |
| Management Software |
Smart PSS, DSS, DMSS |
| Smart Phone |
IOS, Android |
| Port |
| Alarm Event |
No SD card; SD card is full; SD card endurance warning; SD card error; network disconnection; IP conflict; illegal access; Motion detection; video tampering; tripwire; unauthorized entry; scene change; sound detection; voltage detection; external alarm; People counted in the region; maintaining perception; counting people; security exception |
| Certifications |
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Elektromanyetik Uyumluluk Direktifi 2014/30/AB
FCC: 47 CFR FCC Bölüm 15, Alt Bölüm B
UL/CUL: UL62368-1 ve CAN/CSA C22.2 No. 62368-1-14 |
| Electrical |
| Power Supply |
12VDC/PoE+ |
| Power Consumption |
Basic: 6.5 W (12 VDC); 6.1W (PoE)
Max. (ICR + IR intensity): 13 W (12 VDC); 13.9W (PoE)
Heating: 3 W (12 VDC); 3W (PoE) |
| Interface |
| Video Interface |
1/1 channel Input/Output |
| Alarm |
1 channel Input: 5mA 5VDC
1 channel Output: 300mA 12V |
| Environmental |
| Operating Conditions |
–40 °C ila +60 °C (–40 °F ila +140 °F) |
| Strorage Conditions |
–30 °C ila +70 °C (–22 °F ila +158 °F) |
| Ingress Protection |
IP67; IK10 |
| Construction |
| Casing |
Metal |
| Dimensions |
59,8 mm × Φ149,8 mm (2,35" × Φ5,90") |
| Net Weight |
1,21 kg (2,67 lb) |
| Gross Weight |
1,21 kg (2,67 lb) |
