• 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
• Outputs max. 5MP (2592 × 1944) @25/30 fps
• H.265 codec, high compression rate, ultra-low bit rate
• ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
• 120dB WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
• Intelligent detection: Intrusion, tripwire, people counting in area
• Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
• Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic
• 12V DC/PoE power supply, easy for installation
• IP67, IK10 protection
• Heat map for people counting. You can adjust the number of people, time threshold to generate a heat map, which can be exported.
| Dosyalar |
| IPC-EB5541-AS-DataSheet |
Download |
| Camera |
| Image Sensor |
1/2.7” 5Megapixel CMOS |
| Effective Pixels |
2592 (Y) × 1944 (D) |
| RAM/ROM |
128MB/512MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 sn–1/100.000 sn |
| Minimum Illumination |
0.006 Lux@F2.0 (Color, 30IRE) |
| S/N Ratio |
> 56 dB |
| IR Distance |
30m |
| Lens |
| Lens Type |
Fixed Focus |
| Mount Type |
M12 |
| Focal Length |
1,4 mm |
| Max. Aperture |
F2.0 |
| Angle of View |
Horizontal: 180°
Vertical: 180°
Diagonal: 180° |
| Close Focus Distance |
0,2 m (0,7 ft) |
| PTZ |
| Pan/Tilt Range |
Pan: 0°–355°
Tilt: 0°–55°
Rotation: 0°–360° |
| Video |
| Compression |
H.265; H.264; H.264H; H.264B; MJPEG |
| Smart Codec |
Smart H.265+/ Smart H.264+ |
| Streaming Capability |
3 Streams |
| Frame Rate |
Ana akış (2592 × 1944 @1–25/30 fps)
alt akış (704 × 576 @1–25 fps/704 × 480 @1–30 fps)
üçüncü akış (1280 × 720 @1–25/30 fps) |
| Resolution |
5M (2592x1944); 3M (2048x1536); UXGA (1600 x 1200); 1,3M (1280x960); 720p (1280x720); D1 (704x576/704x480); VGA (640x480); CIF (352x288/352x240) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps |
| Day/Night |
Color/S/B |
| BLC Mode |
Yes |
| HLC |
Yes |
| White Balance |
automatic/natural/street light/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| WDR |
120dB |
| Noise Reduction |
3D DNR |
| Region of Interest |
Off / On (4 Zone) |
| Motion Detection |
Off / On (4 Zone, Rectangle) |
| Privacy Masking |
Closed / Open (4 Fields, Rectangular) |
| Audio |
| Compression |
PCM; G.711a; G.711Mu; G726 |
| Network |
| Ethernet |
RJ-45 (100/1000Base-T) |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS'ler; DDNS; QoS; UPnP; NTP; Çok noktaya yayın; ICMP; IGMP; NFS; PPPoE; SNMP |
| Interoperability |
ONVIF (Profil S/Profil G/Profil T); CGI; Dönüm noktası; Genetec; P2P |
| Max. User Access |
20 |
| Edge Storage |
FTP; SFTP; Micro SD card (support max. 256G); of NAS |
| Web Viewer |
IE: IE8, IE9 ve IE11
Chrome
Firefox |
| Management Software |
Smart PSS, DSS, DMSS |
| Smart Phone |
IOS, Android |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; digest; WSSE; account locking; security logs; IP/MAC filtering; Creating and importing the X.509 certificate; system log; HTTPS; 802.1x; reliable boot; reliable execution; reliable upgrade |
| Certifications |
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Elektromanyetik Uyumluluk Direktifi 2014/30/EU
FCC: 47 CFR FCC Bölüm 15, Alt Bölüm B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Electrical |
| Power Supply |
12VDC/PoE |
| Power Consumption |
Basic power consumption: 3.7W (12V DC); 4.7W (PoE)
Max. power consumption (H.265 + smart function + WDR): 5.1 W (12 V DC); 6W (PoE) |
| Interface |
| Video Interface |
1/1 channel Input/Output |
| Alarm |
1 channel Input: 5mA 5VDC
1 channel Output: 300mA 12V |
| Environmental |
| Operating Conditions |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% relative humidity |
| Strorage Conditions |
–40°C ila +60°C (–40°F ila +140°F) |
| Ingress Protection |
IP67; IK10 |
| Construction |
| Casing |
Metal |
| Dimensions |
62,0 mm × Φ110,0 mm (2,44" × Φ4,3") |
| Net Weight |
387 gr (0,9 lb) |
| Gross Weight |
502 gr (1,1 lb) |
