• Max. 30 fps@1080p.
• Smart IR Illumination.
• 20 m illumination distance.
• 3.6 mm fixed lens (2.8 mm,6 mm optional).
• CVI/CVBS/AHD/TVI switchable.
• IP67, 12 VDC.




                          | Dosyalar |



                                      | HAC-B1A21-A-0360B-DataSheet | Download |










                        | Camera |



                          | Image Sensor | 2 MP CMOS |

                          | Effective Pixels | 1920 (Y) × 1080 (D) |

                          | Scanning System | Progressive |

                          | Electronic Shutter Speed | PAL: 1/25 sn–1/100000 sn
NTSC: 1/30 sn–1/100000 sn |

                          | Minimum Illumination | 0.02 lux@F2.0 (Color, 30 IRE)
0.002 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on) |

                          | Illumination Distance | 20 m (65,62 ft) |

                          | S/N Ratio | >65 dB |

                          | IR On/Off Control | Auto |

                          | IR LEDs | 2 |



                        | Lens |



                          | Lens Type | Fixed Focus |

                          | Mount Type | M12 |

                          | Focal Length | 2,8 mm; 3,6 mm; 6 mm |

                          | Max. Aperture | F2.0 |

                          | Angle of View | 2,8 mm: Y: 100°; Dikey: 54°; D: 117°
3,6 mm: Y: 80°; Dikey: 43°; D: 94°
6 mm: Y: 43°; Dikey: 24°; D: 50° |

                          | Close Focus Distance | 2,8 mm: 0,5 m (1,64 ft)
3,6 mm: 0,8 m (2,62 ft)
6 mm: 2,8 m (9,19 ft) |



                        | Audio and Video |



                          | Video Output | CVI/TVI/AHD/CVBS video output options with a BNC port |



                        | Video |



                          | Frame Rate | CVI:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
AHD:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
TVI:
PAL: 1080p@25
fps NTSC: 1080p@30 fps
CVBS:
PAL: 960H;
NTSC: 960H |

                          | Resolution | 1080p (1920 × 1080); 960H (960 × 576/960 × 480) |

                          | Lighting Mode | Smart IR |

                          | Day/Night | Auto(ICR)/Color/B/W |

                          | BLC Mode | BLC; DWDR |

                          | White Balance | Auto |

                          | Gain Control | Auto |

                          | WDR | DWDR |

                          | Noise Reduction | 2DNR |



                        | Certifications |



                          | Certifications | CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
FCC: 47 CFR FCC Bölüm 15, Alt Bölüm B |



                        | General |



                          | Operating Temperature | –40 °C ila +60 °C (–40 °F ila +140 °F) |

                          | Installation | Wall mounting; ceiling mounting; vertical pole installation |



                        | Electrical |



                          | Power Supply | 12 VDC ± %30 |

                          | Power Consumption | Maksimum 2,8 W (12 VDC, IR açık) |



                        | Packaging |



                          | Gross Weight | 0,22 kg (0,49 lb) |



                        | Environmental |



                          | Ingress Protection | IP67 |

                          | Anti-corrosion Level | Basic protection |

                          | Storage Temperature and Humidity | –40 °C ila +60 °C (–40 °F ila +140 °F)
<%95 (RH) |



                        | Construction |



                          | Casing | Plastic |

                          | Dimensions | 149,3 mm × 69,8 mm × 69,8 mm (5,88" × 2,75" × 2,75") |

                          | Net Weight | 0,14 kg (0,31 lb) |
