• 2MP, 1/2,8” CMOS görüntü sensörü, düşük aydınlatma, yüksek görüntü tanımı
• Çıkışlar maks. 2MP (1920 × 1080) @25/30 fps
• H.265 codec'i, yüksek sıkıştırma oranı, ultra düşük bit hızı
• Dahili IR LED, maks. IR mesafesi: 30 m
• ROI, SMART H.264/H.265, esnek kodlama, çeşitli bant genişliği ve depolama ortamlarına uygulanabilir
• Döndürme modu, WDR, 3D DNR, HLC, BLC, dijital filigranlama, çeşitli izleme sahnelerine uygulanabilir
• Akıllı algılama: İzinsiz giriş, tetikleme kablosu
• Anormallik tespiti: Hareket algılama, video kurcalama, SD kart yok, SD kart dolu, SD kart hatası, ağ bağlantısı kesilmesi, IP çakışması, yasa dışı erişim, voltaj algılama
• Maks. 256 GB Mikro SD kart, dahili Mikrofon
• 12V DC/PoE güç desteği
• IP67 koruması
| Dosyalar |
| IPC-HDW2231TM-AS-0280B-S2-DataSheet |
Download |
| Camera |
| Image Sensor |
1/2.8”2Megapixel progressive CMOS |
| Effective Pixels |
1920(H) x1080(V) |
| RAM/ROM |
128MB/128MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual, 1/3~1/100000s |
| Minimum Illumination |
0.002 Lux @F1.6 |
| IR Distance |
30m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
2 |
| Lens |
| Lens Type |
Fixed |
| Mount Type |
M12 |
| Focal Length |
2.8 mm
3.6 mm |
| Max. Aperture |
F1.6 |
| Angle of View |
2.8 mm:
Horizontal:106°
Vertical: 56°
Diagonal: 126°
3.6 mm:
Horizontal:87°
Vertical: 46°
Diagonal: 104° |
| Close Focus Distance |
2.8 mm: 0.6 m (2.0 ft)
3.6 mm: 1.2 m (3.9 ft) |
| Video |
| Compression |
H.265; H.264; H.264B; MJPEG |
| Smart Codec |
Yes |
| Streaming Capability |
2 Streams |
| Frame Rate |
Main stream:
1920 × 1080 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps) |
| Resolution |
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 32 Kbps–6144 Kbps
H.265: 12 Kbps–6144 Kbps |
| Day/Night |
Auto(IR-Cut) / Color / B/W |
| BLC Mode |
Yes |
| HLC |
Yes |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Region of Interest |
Off / On (4 Zone) |
| Motion Detection |
Off / On (4 Zone, Rectangle) |
| Smart IR |
Yes |
| Mirror |
Off / On |
| Privacy Masking |
4 areas |
| Audio |
| Compression |
G.711A; G.711Mu; G.726; AAC |
| Built-in MIC |
YEs |
| Network |
| Ethernet |
RJ-45 (10/100 Base-T) |
| Protocol |
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP |
| Interoperability |
ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec |
| Max. User Access |
20 |
| Edge Storage |
Dahua Cloud; FTP; Micro SD Card (support max. 256 GB); NAS |
| Web Viewer |
IE, Chrome, Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Smart Phone |
IOS, Android |
| Certifications |
| Certifications |
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B |
| Electrical |
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
< 6.5W |
| Environmental |
| Operating Conditions |
-40°C to +60°C (-40°F to +140°F)/less than ≤ 95% |
| Strorage Conditions |
-40°C to +60°C (-40°F to +140°F) |
| Ingress Protection |
IP67 |
| Construction |
| Casing |
Metal+Plastic |
| Dimensions |
99.1 mm × Φ121.9 mm (3.9" × Φ4.8") |
| Net Weight |
0.48 kg (1.1 lb) |
| Gross Weight |
0.65 kg (1.4 lb) |
