• 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition
• Outputs max. 2MP (1920 × 1080) @25/30 fps
• H.265 codec, high compression rate, ultra-low bit rate
• Built-in IR LED, max. IR distance: 30 m
• ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
• Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
• Intelligent detection: Intrusion, tripwire
• Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection
• Supports max. 256 GB Micro SD card
• 12V DC/PoE power support
• IP67 protection
| Dosyalar |
| IPC-HFW2231S-S-0360B-S2-DataSheet |
Download |
| Camera |
| Image Sensor |
1/2.8”2Megapixel progressive CMOS |
| Effective Pixels |
1920 (H) ×1080 (V) |
| RAM/ROM |
128 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
| Minimum Illumination |
0.002 Lux @F1.6 |
| IR Distance |
30 m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
1 |
| Lens |
| Lens Type |
Fixed |
| Mount Type |
M12 |
| Focal Length |
2.8 mm
3.6 mm |
| Max. Aperture |
F1.6
F1.6 |
| Angle of View |
2.8 mm:
Horizontal:106°
Vertical: 56°
Diagonal: 126°
3.6 mm:
Horizontal:87°
Vertical: 46°
Diagonal: 104° |
| Close Focus Distance |
2,8 mm: 0,6 m (2,0 ft)
3,6 mm: 1,2 m (3,9 ft) |
| Video |
| Compression |
H.265; H.264; H.264B; MJPEG |
| Streaming Capability |
2 Streams |
| Resolution |
1080p (1920 × 1080); 1,3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 32 Kbps–6144 Kbps
H.265: 12 Kbps–6144 Kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC Mode |
Yes |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Network |
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol |
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 |
| Edge Storage |
Dahua Bulutu; FTP; Mikro SD Kart (maks. 256 GB desteği); NAS'ın |
| Web Viewer |
Dahua Bulutu; FTP; Mikro SD Kart (maks. 256 GB desteği); NAS'ın |
| Management Software |
Akıllı PSS; DSS; DMSS |
| Smart Phone |
IOS; Android |
| Certifications |
| Certifications |
CE-LVD: EN60950-1
CE-EMC: Elektromanyetik Uyumluluk Direktifi 2014/30/EU
FCC: 47 CFR FCC Bölüm 15, Alt Bölüm B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Electrical |
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
< 4,9W |
| Environmental |
| Operating Conditions |
-40°C to +60°C (-40°F to +140°F)/less than ≤ 95% |
| Strorage Conditions |
40°C ila +60°C (-40°F ila +140°F) |
| Ingress Protection |
IP67 |
| Construction |
| Casing |
Metal |
| Dimensions |
166,2 mm × Φ70 mm (6,5" × Φ2,8") |
| Net Weight |
0,48 kg (1,1 lb) |
| Gross Weight |
0,57 kg (1,3 lb) |
